ComFlor 210 Alternative Steel Deck | Eurocode 4, EPD & BES 6001 Certified

Standard & Certification Compliance​

As an alternative to ComFlor® 210, this product is designed and tested in full compliance with Eurocode 4 (covering cold‑formed steel, composite structure and fire resistance criteria) and BS 5950 specifications. Verified via industry‑standard analysis for construction-stage performance, service loads and fire behavior, it holds dual international standard recognition. This eliminates repeated certification work, enabling smooth project adoption across Europe, the UK, the Middle East and Asia.


BES 6001 & EPD Sustainability Credentials​​

1.
   BES 6001: Rated "Very Good" for full-chain ethical raw material procurement and manufacturing. Valid for BREEAM, LEED green building credits, mandatory for public infrastructure projects worldwide.
2. EPD: Third-party certified under ISO 14025 & EN 15804, recording embodied carbon and environmental impacts. Compulsory for landmark projects including Dubai Metro, satisfying international tender sustainability rules.


Core Specifications & Advantages​​

Fire Resistance Performance​​

With optimized rib structure and reinforcement layout, this ComFlor 210 equivalent delivers 2‑hour soffit fire resistance without fireproof coating, fully compliant with codes for commercial, educational and medical buildings. It achieves 60‑minute fire protection with encastre beams. Anti‑crack mesh designed per BS 5950 & Eurocode 4 ensures stable slab performance under fire conditions.


Slim Floor System Application​​

Installed on the bottom flange of asymmetric beams, the floor slab is contained within beam depth to bring multiple benefits:

• Reduce total building height and add one extra floor for 10+ storey buildings
• Cut exterior cladding costs
• Conceal mechanical services inside slab ribs to save indoor vertical space It also adapts to traditional beam layouts for flexible engineering designs.


Concrete Allocation & Slab Size​​

Applicable slab depth: 260mm–400mm. Its streamlined rib structure consumes less concrete than ordinary floor slabs and lessens foundation load and main steel weight. Adjustable slab thickness accommodates office light loads and industrial heavy loads flexibly.


Export & Logistics Merits​​

The nestable trapezoidal shape raises loading quantity per bundle and container to lower transportation fees. Two workers can lay over 400 m² per day; hoisting and concrete pouring proceed rapidly to accelerate project progress, delivering prominent cost edges for global export orders.
