Nestable ComFlor 210 Equivalent Decking | Higher Container Load, Lower Sea Freight

Equivalent to ComFlor 210, this deep long-span composite floor deck is engineered for Slimflor® integrated floor systems. Constructed with 1.25mm S280GD+Z275 hot-dip galvanized steel that meets BS EN 10346 standards, it comes with 350 N/mm² minimum yield strength and 275g/m² double-sided zinc coating. Its standout overseas merit lies in the nestable trapezoidal profile: tight stacking raises bundle and container loading volume substantially, lowering ocean freight costs, easing cargo management and shortening construction schedules for worldwide customers. Capable of 6m unpropped spans and 9m propped spans, it combines reliable load-bearing performance with cost-efficient international transportation.

Nestable Design: Core Export Benefit​

The special trapezoidal outline brings remarkable logistics superiority unavailable to ordinary floor decks:

• •More square meters loaded in each container, fully utilizing internal container space
• •educed total ocean freight cost per square meter of decking
• •Fewer cargo bundles to lower loading, unloading and onsite transportation workload
• •Less transportation frequency cuts carbon emission for greener construction procurement


Container Loading & Logistics Parameters​​

Custom panel lengths match standard shipping containers to achieve optimal space utilization:

Compact nesting configuration maximizes every cubic meter of container space and prominently lowers unit shipping cost.


Onsite Installation Efficiency​​

The logistics advantages extend to construction sites after delivery:

• •Compact bundled goods speed up crane unloading work
• •Lightweight bundles are easy for construction teams to carry and arrange
• •Two workers can lay over 400 m² decking per day
• •Only simple anti-crack mesh and pumped concrete are needed, shortening the whole floor construction cycle


Key Specifications & Comprehensive Advantages​​

Fire Resistance & Structural Stability​​

The deep rib structure plus optimized reinforcement layout delivers stable fire resistance without additional fireproof paint. It reaches 2-hour fire endurance to meet commercial, education, medical and residential building codes; 60-minute fire protection can be realized effortlessly with encastre beams. Single steel bar reinforcement inside each rib matched with top anti-crack mesh maintains slab integrity and structural safety under fire conditions.


Slim Floor System Application​​

Installed on the bottom flange of asymmetric steel beams, the floor slab is embedded within beam depth to create multiple economic values:

• •Reduce overall building height and add one extra usable floor for buildings above 10 storeys
• •Cut exterior wall cladding material costs
• •Mechanical pipelines can be laid inside rib gaps to save indoor vertical space It is also adaptable to traditional beam structures with flexible application scenarios.


Sustainable Performance​​

Manufactured with standardized ethical production processes, the product gains BES 6001 "Very Good" certification and official EPD environmental report certified by ISO 14025:

• •Nested stacking cuts shipment frequency and transport carbon emissions
• •Stiffener design minimizes steel and concrete consumption
• •Compact packaging lowers production and construction waste

It can be used to apply for LEED, BREEAM green building credits, satisfying strict sustainability requirements for global infrastructure bidding projects.
