EN 10025 S235JR/S355JR galvanized H beam UB/UC available for Europe
| Place of Origin | China |
|---|---|
| Brand Name | FASEC |
| Certification | EN 10204 3.1/3.2 Mill Test Certificates; ISO 9001 |
| Model Number | H Beam Steel |
| Minimum Order Quantity | 1000 MT |
| Price | USD 500 – 800 / MT |
| Packaging Details | Sea Freight (Container/Bulk Vessel) |
| Delivery Time | 10-30 Days |
| Payment Terms | L/C, D/A, D/P, T/T |
| Supply Ability | 2,000 – 5,000 MT/month |
Product Details
| Standard | EN 10025-2; Dimensional Tolerance EN 10210-1 | Material Grades | S235JR, S355JR |
|---|---|---|---|
| Surface Treatment | Hot-dip Galvanized | Profile Series | HW, HM, HN, HP |
| Applications | High-rise Buildings, Industrial Warehouses, Bridge Engineering, Port Infrastructure, Heavy Equipment Bases, Seismic-resistant Frames | Customization | Customized To Project Requirements |
Product Description
EN 10025 S235JR/S355JR Galvanized H Beam conforms strictly to EN 10025-2. Available in S235JR and S355JR, the UB & UC sections are widely adopted for European steel construction. Treated with hot-dip galvanizing, the beams feature outstanding corrosion resistance, stable mechanical performance and good weldability, fully satisfying European building code requirements.
EN 10025-2 Grades – S235JR VS S355JR
| Parameter | S235JR | S355JR |
|---|---|---|
| Steel Type | Non-alloy structural steel | High-strength low-alloy steel |
| Min Yield Strength (≤16mm) | ≥235 MPa | ≥355 MPa |
| Tensile Strength | 360 – 510 MPa | 470 – 630 MPa |
| Elongation | ≥26% | ≥21% |
| Impact Energy (20°C) | 27 J | 27 J |
| Equivalent Grade | Q235B / A36 | Q355B / A572 Gr.50 |
| Typical Use | Light & medium load structures | High-rise, bridges, heavy-load projects |
S235JR balances strength, ductility and cost for general construction. S355JR features higher yield strength, ideal for heavy-duty and long-span engineering projects.
Standard Compliance: EN 10025-2 & EN 10210-1
All products follow EN 10025-2 for chemical composition and mechanical properties. Dimensional tolerances comply with EN 10210-1. Each batch comes with EN 10204 3.1 mill test certificates, complete with marking of steel grade, profile type and standard information.
All products follow EN 10025-2 for chemical composition and mechanical properties. Dimensional tolerances comply with EN 10210-1. Each batch comes with EN 10204 3.1 mill test certificates, complete with marking of steel grade, profile type and standard information.
UB & UC European Standard Profiles
• UB (Universal Beams): Mainly used as horizontal beams for floors, roofs and bridge girders, size range: UB 127×76 ~ UB 1016×305- • UC (Universal Columns): Designed for vertical load-bearing columns and supports, size range: UC 152×152 ~ UC 356×406
Custom cut-to-length service is available to match different project layouts.
Hot-Dip Galvanized Anti-Corrosion Treatment
Hot-dip galvanizing forms a compact zinc coating to resist moisture, atmospheric erosion and freeze-thaw cycles. The coating fully covers all surfaces including edges and corners. On-site painting can be omitted, lowering construction and long-term maintenance costs.
Hot-dip galvanizing forms a compact zinc coating to resist moisture, atmospheric erosion and freeze-thaw cycles. The coating fully covers all surfaces including edges and corners. On-site painting can be omitted, lowering construction and long-term maintenance costs.
Structural Advantages
Parallel flange design and optimized cross-section deliver high bending resistance and section modulus. Compared with ordinary I-beams, it improves load efficiency and reduces steel consumption. Excellent toughness and stability make it suitable for dynamic loads, vibration and seismic building structures, effectively lowering the overall dead weight of steel buildings.
Application Scope
• High-rise commercial & residential buildings: columns, main beams and floor frames- • Industrial warehouses: roof trusses and crane supporting structures
- • Bridge engineering: main girders and cross beams
- • Transportation & port infrastructure supports
- • Heavy equipment foundation and mounting bases
- • Earthquake-resistant steel framing systems
Suitable for European Market
Specially produced to match European design specifications. EN standard certification, mature UB/UC size system and galvanized finish enable direct use in EU and UK projects, compatible with local design codes, fabrication and installation habits.
Specially produced to match European design specifications. EN standard certification, mature UB/UC size system and galvanized finish enable direct use in EU and UK projects, compatible with local design codes, fabrication and installation habits.
Why Choose Our Galvanized H Beams?
We provide EN-standard certified H beams with complete material traceability. Multiple grades of S235JR / S355JR, UB & UC profiles and hot-dip galvanized treatment are available. Strict quality control ensures stable performance to meet European engineering procurement demands.
Request Your Quotation Today
We welcome enquiries from engineers, contractors and steel fabricators across Europe. Our team provides technical datasheets, EN 10204 3.1 test certificates and tailored quotations.
Contact us now for European standard galvanized H beam solutions. Product supplied by Hangzhou FAMOUS Steel Engineering Co., Ltd., China
