Street Pedestrian Bridge Steel Girder Box Typical Triangulated Rapid
| Place of Origin | Zhejiang, China |
|---|---|
| Brand Name | FASEC |
| Certification | ISO9001:2008, SGS, etc. |
| Minimum Order Quantity | 1 pcs |
| Price | USD1000~USD1200 per ton |
| Packaging Details | Seaworthy packings into container or bulk vessel |
| Delivery Time | Based on client's needs |
| Payment Terms | L/C,T/T |
| Supply Ability | 600,000 tons per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model Number | CB100(321-Type)&HD200 | Material | Q345B Steel |
|---|---|---|---|
| Surface Treatment | Painted Or Hot Dip.etc | Size | According To Client's Need |
| Installation | Lifted Into Place By Hand Without Crane, Easier Construction.etc | Multi-use | Civil Engineering Construction Projects And To Provide Temporary Crossings For Foot & Vehicle Traffic. |
| Carry Capacity | Resist Strong Wind And Earthquake, Bears Heavy Snow.etc | Grade | Q345B-Q460C |
| Color | Army Blue, Light Gray, Hot Galvanized Or Customized.etc | ||
| High Light | street pedestrian bridge steel girder,pedestrian bridge steel girder Box,steel girder pedestrian bridges |
||
Product Description
Box girder bridges are quite common .They are usually manufactured from prefabricated steel girders. This means that the girders are manufactured in a factory and transported to the location of the bridge, where they are fixed together. The steel girders of a bridge are fixed together normally with large nuts and bolts. Sometimes rivets are used although these are seen on older structures.
Specification:
| Product Name | Cable-stayed bridge |
| Width | 4.2m, 3.7m, 4m, 7.56m etc |
| Maximum span | 81meter single span or 200m multi-span |
| Bridge deck | Steel composit panel |
| Steel grade | Q345B (equivalent to ASTM A572) or Q460B |
| Loading capacity | 20ton, 40ton up to 120ton truck etc, |
| Corrosion | Original painted or Hot dip galvanized |
Each side of the bridge is composed of three triangles. Each triangle is made up of three steel girders bolted together. This is called triangulation and produces a structure of great strength.
An example of girders bolted together can be seen below. The girders in diagram ‘A’ have been made slightly transparent so that the bolts penetrating both girders can be seen. Diagram ‘B’ shows the girders and bolts as they are normally seen.
Normally bridges and other structures made from prefabricated steel are bolted together even though it is expected that they will be permanent structures. Fixing girders together with bolts is faster, more efficient and safer than using ‘red’ hot steel rivets (See construction of the Empire State Building).
