Bespoke Galvanised Heavy Steel Fabrication Grid Structure Large Venue Roof Seismic

  • Bespoke Galvanised Heavy Steel Fabrication Grid Structure Large Venue Roof Seismic
  • Bespoke Galvanised Heavy Steel Fabrication Grid Structure Large Venue Roof Seismic
  • Bespoke Galvanised Heavy Steel Fabrication Grid Structure Large Venue Roof Seismic
Place of Origin China
Brand Name FASEC
Certification CE, ISO, SGS
Model Number HZFS
Minimum Order Quantity 20 tons
Price USD1000-2600/ton
Packaging Details Seaworthy packing in container or bulk vessel
Delivery Time As per client's needs like 2-3 months
Payment Terms L/C, T/T, D/A, D/P
Supply Ability 100000 tons per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Steel Grade Q345B, Q355B
Type Heavy Width 500mm-2200mm
Length 5000-12000mm Surface Treatment Galvanized
Color Customized Color Application Gymnasiums, Theaters, Exhibition Halls, Waiting Halls, Stadium
High Light

bespoke steel fabrications

,

FASEC HZFS galvanised steels fabrications

,

galvanised steels fabrications FASEC
Leave a Message
Product Description

Seismic Performance Heavy Steel Grid Structure Fabrication for Large Venue Roof Structure

The grid structure is a space structure composed of multiple rods connected by nodes in a certain grid form. It has the advantages of small space force, light weight, high rigidity and good seismic performance; it can be used as the roof of buildings such as gymnasiums, theaters, exhibition halls, waiting halls, stadium stand awnings, hangars, and two-way large column spacing workshops.



There are many types of grid structures, which can be classified according to different standards:
1. According to the structure of the grid itself, it can be divided into: single-layer grid structure, double-layer grid structure; and three-layer grid structure. Among them, the single-layer grid frame and the three-layer grid frame are respectively suitable for the cases with small span (not more than 30m) and very large span (more than 100m), and are rarely used in domestic engineering.
2. According to the construction materials, it is divided into: steel mesh frame, aluminum mesh frame, wood mesh frame, plastic mesh frame, reinforced concrete mesh frame and combined mesh frame (such as the combined mesh frame of steel mesh frame and reinforced concrete slab, etc.), Among them, the steel grid has been widely used in my country, and the combined grid can also be used as a floor layer structure.





Specification:

Item Name Seismic Performance Heavy Steel Grid Structure Fabrication for Large Venue Roof Structure
Main Steel Steel structure--Q345b/Q355b, special high tension plate, etc.
can be customized according to customer's requirements.
Surface Hot Dip Galvanized, or according to customer's requirements.
Connection method welding connection or bolt connection, etc.
Column and Beam Welded H section, Hot Rolled Section Steel, grid column, pipe&tube column,etc.
Service

Design, Detailing, Fabrication and Installation
(Standard: America Standard, Australia Standard, England Standard, China Standard, etc.
Design and Detailing software: SAP2000, Auto CAD, PKPM, RSTAB, PROE, MTS, 3D3S, Tarch, Tekla Structures(Xsteel), etc.

We also can process/fabricate according to client's sample or drawings.)
Making quotation according to customer's drawing or as per customer's dimension and requirement;
Offering a free preliminary design drawing(formal complete design need to be paid [high-quality, low-cost] ).
Packing We possess the unique most professional and best packaging in China presently - framing package, which perfectly protects the structural steel members from any impact damage during the transport.
Or according to customer's requirement.

Load into 40/20GP, 40HQ, 40OT or Bulk carrier



Features:

The grid structure is a space rod structure, and the stressed rods are connected according to certain rules through nodes. The nodes are generally designed to be hinged, the rods are mainly subjected to axial force, and the cross-sectional size of the rods is relatively small. The rods that meet in these spaces support each other, and organically combine the force-bearing rods with the support system, so the material is economical. Due to the regular structure combination, a large number of rods and nodes have the same shape and size, which is convenient for factory production and easy to install on site.
The grid structure is generally a high-order statically indeterminate structure, which can better withstand concentrated loads, dynamic loads and asymmetric loads, and has good seismic performance. The grid structure can adapt to the requirements of public buildings and factories with different spans and different supporting conditions, as well as different building planes and their combinations.



Application:
Roofs of gymnasiums, theaters, exhibition halls, waiting halls, stadium stand awnings, hangars, two-way large column distance workshops, etc.
