Arch Prefabricated Steel Truss Bridge Design Portable Multi Trusses

New design China low price Steel Frame Multi Trusses Prefab Bailey Portable Steel Structure Bridge

Product Parameters

Truss Charactistic
(1)Professional welding technology,beautiful outline and polishing finish
(2)Lightweight but strong loading capacity,durable and firm
(3)Made by aluminum alloy,stable and energy saving
(4)Long span,widely used for different scale of different occasion
(5)Superior raw material,high quality and cheap price

Product Description

Used Portable Bridge Bailey Bridge For Sale Compact Panel Bridge

Product performance

Compact panel bridge , also named as Bailey bridge, is a kind of portable bridge which is widely used in both military field and civil field in the world. It possesses the features of simple structure, few components, convenient transport and easy disassembling and has been modified to many types. The popular types in the worldwide are Bailey bridge CB100 and CB200.

Main technical data

The panel is the basic components of the Bailey bridge, with a dimension of 3.048*1.448m(type 100) and 3.048*2.134m(type 200). The length of the bridge changes by 3.048m(10ft) as a segment to construct various span and various loading bridges.

The bridge adopts a modular design and uses various combinations to meet the needs of different spans and loads. CB100 and CB200 panels are 3.048m long, with 3.048m as a unit change. The width of a single lane is 3.15 meters or 4.2 meters, and the double lane is 7.35 meters.

Dimension:
1. Spigot truss:
230x230mm / 290x290mm / 390x390mm / 520x520mm etc
2. Bolt truss:
100x100mm / 150x150mm / 200x200mm / 250x250mm / 300x300mm / 350x350mm / 400x400mm, 450x450mm / 400x600mm / 500x500mm / 500x600mm / 520x760mm / 600x760mm / 760x910mm;
3. Shape: Ladder truss, triangle truss, sqaure truss, round/circle truss, arc and anomalistic truss
Project: Tower truss system; with flat roof; with triangle roof; with pentroof; with two wings; with portable stage; with tent^. etc. You can hang LED, lighting, tent, sound, LED screen and banner on the truss, suitable for displays, exhibitons, show, concert, performance, events, etc., finish in a snap, very strong, convenient for set up and transportation.
