Steel Prefabricated Truss Bridge Concrete Deck Single Storey Double Lanes Permanent
| Place of Origin | China |
|---|---|
| Brand Name | FASEC |
| Certification | IS09000 |
| Model Number | NO.889 |
| Minimum Order Quantity | 5 sets |
| Price | USD 700-1000 PER TON |
| Packaging Details | container package |
| Delivery Time | 15 working days |
| Payment Terms | L/C, T/T |
| Supply Ability | 100000 ton per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Warranty | One Year For Main Parts | After-sales Service Provided | Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Online Support |
|---|---|---|---|
| Surface Treatment | Hot Dip Galvanized And Painted | Grade | Q235 Q345 & Q355B Steel |
| Performance | Safety, Convenient, Install Easily Etc. | Size | Customized Size |
| High Light | steel prefabricated truss bridge,prefabricated truss Bridges Single Storey,prefab steels truss Single Storey FASEC |
||
Product Description
Prefabricated Single Storey Double Lanes Permanent Assembly Concrete Deck Steel Truss Bridge
Specification
| Type | CB100 | CB200 | CB200A | CB250 |
| Design Span | 6-60m | 6-54m | 6-60m | 35-87.5m |
| Design Load | HS25-44,Axle load 20t,track load 50t | HL93,HA,HB,track load 60t | HL93,HA,HB,track load 60t | HS20-44,HL93,HA,HB,track load 60t |
| Panel Dimension | 1.448*3.048m | 2.134*3.048m | 2.134*3.048m | 2.4*5.84m |
| Carriageway Width(singaldouble lane) | 4.2m7.35m | 4.2m7.35m | 4.2m7.35m | 4.2m7.35m |
| Deck Type | steel deckwood deck | steel deck | steel deck | steel deck |
1. Both vertical and lateral stiffness are greater than simply supported beams, and the internal force distribution is more reasonable
2.For multi-hole bridges with a span greater than 120m, it is more reasonable to use continuous truss beams. Steel materials can save about 8-10% compared with simply supported beams.
3.Structural layout
The number of spans per joint is two or three spans, rarely more than five spans.
Two-hole continuous beam should be made of equal span.
The reasonable ratio of the span of the three holes is 7:8:7. For the sake of beauty, an equal-span layout is often used.
Beam height: usually 1/7~1/8 of the span, the support can be increased appropriately.
Truss Charactistic
(1)Professional welding technology,beautiful outline and polishing finish
(2)Lightweight but strong loading capacity,durable and firm
(3)Made by aluminum alloy,stable and energy saving
(4)Long span,widely used for different scale of different occasion
(5)Superior raw material,high quality and cheap price
Dimension:
1. Spigot truss:
230x230mm / 290x290mm / 390x390mm / 520x520mm etc
2. Bolt truss:
100x100mm / 150x150mm / 200x200mm / 250x250mm / 300x300mm / 350x350mm / 400x400mm, 450x450mm / 400x600mm / 500x500mm / 500x600mm / 520x760mm / 600x760mm / 760x910mm;
3. Shape: Ladder truss, triangle truss, sqaure truss, round/circle truss, arc and anomalistic truss
Project: Tower truss system; with flat roof; with triangle roof; with pentroof; with two wings; with portable stage; with tent^. etc. You can hang LED, lighting, tent, sound, LED screen and banner on the truss, suitable for displays, exhibitons, show, concert, performance, events, etc., finish in a snap, very strong, convenient for set up and transportation.
