AS/NZS 5131 Certified Steel Fabrication for Australian Projects – AS/NZS 3678, 3679, 1554 & AS 4100

For Australian projects, steelwork is not just about cutting and welding — it is about proving compliance from design to delivery. We fabricate structural steel, built-up sections, pipe and tubular structures, and custom components for clients who need to satisfy the National Construction Code and their project specifications.

This overview explains how we link AS 4100, AS/NZS 3678, AS/NZS 3679, AS/NZS 1554, and AS/NZS 5131 into one traceable fabrication process — so you get steelwork that is compliant, documented and ready for site.

Why This Standard Chain Matters

Australian structural steel projects are governed by a linked chain of standards — not a single one. AS 4100 is the design standard called up by the National Construction Code. But design compliance alone is not enough: steelwork designed to AS 4100 must be fabricated and erected to AS/NZS 5131. In turn, AS/NZS 5131 requires steel products to meet AS/NZS 3678 (plates) and AS/NZS 3679 (bars and sections), with welding complying with AS/NZS 1554.

Pillar 1: Design — AS 4100

AS 4100 is the complying standard for structural steel design in Australian buildings under the National Construction Code. Where imported materials are involved, AS 4100 sets out specific requirements for material identification, test certification and traceability.

What we apply:

• Design compliance reviewed against AS 4100 requirements before fabrication

• Material grade verification against design specification

• Test certificates traceable to specific heat numbers

• Shop drawings prepared with design compliance notes

Pillar 2: Material — AS/NZS 3678 & AS/NZS 3679

All steel is sourced to Australian material standards with full certification.

What we provide:

• Material test certificates traceable to heat number and project mark

• Mill certificates matching the specified grade

• Weathering steel options available

Pillar 3: Welding — AS/NZS 1554

Welding is performed to AS/NZS 1554 — the Australian structural steel welding standard. All welding procedures are qualified and project-specific, with records maintained for every job.

What we apply:

• AS/NZS 1554 qualified WPS/PQR for all welding procedures

• Certified welders qualified to AS/NZS 2980 or ISO 9606.1

• Welding coordination per AS/NZS ISO 3834 and ISO 14731

• Welding Inspector review of all qualification documents and inspection records

Pillar 4: Fabrication & Certification — AS/NZS 5131

AS/NZS 5131 defines the fabrication and erection requirements for structural steelwork to achieve compliance with the National Construction Code. Certification requires a factory quality management system built on ISO 9001, a welding management system built on ISO 3834, and a project-specific Inspection and Test Plan (ITP) with full traceability.

What we apply:

• Construction Category (CC) assessment — CC2 or CC3 as specified by the project

• Traceability system — material certificates, process records, welding records and NDT records maintained throughout fabrication

• ITP prepared for each project and aligned with AS/NZS 5131 requirements

• Surface treatment and corrosion protection applied per AS/NZS 5131

• Geometrical tolerances controlled to AS/NZS 5131 Appendix F — Functional and Essential tolerances

Note: AS/NZS 5131 certification covers different Construction Categories. We can discuss the CC level appropriate to your project and confirm the scope of coverage.

What We Fabricate

Documentation Package

Each shipment includes:

• Material Test Certificates — traceable to heat number and project mark

• WPS/PQR — AS/NZS 1554 qualified welding procedure specifications

• Welder Certificates — AS/NZS 2980 or ISO 9606.1 qualified

• Welding Coordination Records — per AS/NZS ISO 3834

• ITP Records — inspection and test plan sign-offs

• NDT Reports — visual, MT, PT, UT or RT inspection as specified

• Dimensional Inspection Records — tolerance verification per AS/NZS 5131

• Surface Treatment Records — coating and corrosion protection documentation

• As-built Shop Drawings — with component marks and erection sequence

• Packing List — weights, dimensions and drawing references

Why Choose FASECbuilding?

At Hangzhou FAMOUS Steel Engineering Co., Ltd. (FASECbuilding), we bring over 20 years of experience in steel structures and fabrication and exports to more than 100 countries and regions, specialising in steel bridges, factory buildings, trusses, composite floor decking and custom steel components — with dedicated capability for Australian and New Zealand standard projects.

When you work with us, you get:

• Full AS/NZS standard chain capability — 3678, 3679, 1554, 5131 and AS 4100

• AS/NZS 5131 compliant quality system — documented and traceable

• AS/NZS 1554 qualified welding — WPS/PQR, certified welders, inspection

• Material certificates traceable to heat number — ready for Australian project documentation

• OEM/ODM — built to your drawings, not from a catalogue

• Export packing and worldwide shipping with full logistics support

Send us your drawings, required construction category and project specification today for a free quotation and technical proposal — Hangzhou FAMOUS Steel Engineering Co., Ltd. (FASECbuilding) is ready to fabricate your steelwork to the full Australian standard chain.
